Enable: 0 = disables outputs
1 = enables outputs
Examples Syntax Explanation
Command: DPTX:DTOP 1 Enables the outputs.
Query: DPTX:DTOP? Queries to determine if the link training out-
puts are enabled or disabled.
DPTX:EMPH
DPTX:EMPH? Sets the pre-emphasis level of the link.
Query the current setting fo the pre-emphasis.
Arguments Valid Values
Preemphasis: 0 = no pre-emphasis
1 = pre-emphasis level 1
2 = pre-emphasis level 2
3 = pre-emphasis level 3
Examples Syntax Explanation
Command: DPTX:EMPH 1 Sets pre-emphasis to level 1
Query: DPTX:EMPH? Queries the current value of the pre-empha-
sis level parameter.
DPTX:FLRC
DPTX:FLRC? Forces a link rate and lane count regardless of the link training status.
Queries for the current value of the link rate parameter.
Arguments Valid Values
Link rate: 0 = 1.62Gb/s
1 = 2.7Gb/s
Lane count: 1 = one lane
2 = two lanes
4 = four lanes
Examples Syntax Explanation
Command: DPTX:FLRC 1 4 Sets the link rate to 2.7Gb/s and the lane
count to 4 lanes.
DPTX:LLCT? Runs the specified link layer tests a specified number of times.
Arguments Valid Values
Test number: 0 - 22
Test runs: 1 to 10
Examples Syntax Explanation
Command: DPTX:LLCT? 3 4 Causes the link layer test number 5.2.1.4 to
be run 4 times.
DPTX:LNKU Performs link training using the set of values for number of lanes, link rate, etc.
Arguments Valid Values
N/A N/A
