881/882 Video Test Generator User Guide (Rev A.22) 631
6. Verify that the repeater is sending in video using the Timing measurement function of
the analzyer. Refer to “ To view timing information of an external HDMI/DVI source
signal on a display: ” on page 246 for information on running the timing test.
Verify that the repeater is outputting one of the following formats:
• 640x480p at 59.94/60Hz
• 720x480p at 59.94/60Hz
• 720x576p at 50Hz
If the 882 cannot detect the incoming video, enter the following command to turn on the
EST:
QD:PROD:EST // Turns on the EST
7. Press the Tools key and choose the Reports item by pressing the adjacent soft key.
The following is displayed on the generator’s LCD.
8. Select HDCP to access the HDCP compliance test menu.
The following is displayed on the generator’s LCD.
9. Select EditPCP to define the capabilities of the HDCP device under.
The following is displayed on the generator’s LCD.
The following table describes the test parameters and their settings (gray = N/A).
Parameter Explanation
DUT type The type of device under test. This can be one of Sink,
Source, Repeater, Repeater3AB, or Repeater3C. For
this test, select Repeater3AB.
Source Max KSV Specifies the maximum number of KSVs the source can
read. The valid values are 1 through 127.
EDID Packets
Misc HDCP
!CompRpt EditPCP
Source :DUT Type
0
1
+Source_Out_OnlyRep :Source_Authe_Cnt
:Source_Max_KSV
