881/882 Video Test Generator User Guide (Rev A.22) 623
2. For the 882CA connect the cables as follows:
a. Connect an HDMI cable from the repeater device under test output to the 882
HDMI Rx 1 port.
b. Connect an HDMI cable from a compliant source device such as a DVD player
(shown) to the input of the repeater device under test.
The following diagram depicts the test setup for the 882CA:
3. Activate the HDMI-H interface on the output port as follows:
c. Press the Interface key. A listing of signal interfaces appears on the generator’s
display as shown below.
d. Choose the HDMI-H item by pressing the adjacent soft key. The interface is
activated and the display is shown below.
Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Activates the HDMI-H interface
ALLU // Applies the interface setting to the generator
4. Press the Interface key repeatedly until the following menu appears:
5. Choose the HDMI IN 1 by pressing the adjacent soft key.
HDMI/HDCP HDMI/HDCP
Source
DVD
Repeater
DUT
Sink
882CA
HDMI In
VGA
HDMI-D CVBS
S-VIDEO
SDI
*
HDMI-H
VGA
HDMI-D CVBS
S-VIDEO
SDI *HDMI-H
HDMI IN 1
HDMI IN 2 *
