456 Chapter 14 DisplayPort Link Layer Testing
3. Press the Options key. The following information appears on the generator’s display.
4. Choose the EDID Formats item by pressing the adjacent soft key. A + appears next to
EDID Formats indicating enabled.
The generator loads the Source list with formats supported by the connected display
(hot-plug formats read via EDID structure of attached display).
5. To redisplay all formats, press the soft key adjacent to EDID Formats. A ‘-’ (minus sign)
next to EDID Formats indicates it is disabled.
To use Emulate mode:
Emulate mode reads the EDID of the connected display and sets the output based on the
preferred format and also sets the color space.
1. Connect the 882 to the display you want to test.
2. Press the Sink key. The following information appears on the generator’s display.
3. Press the Options key. The following information appears on the generator’s display.
4. Choose the Emulate item by pressing the adjacent soft key. A + appears next to
Emulate indicating enabled.
Alternatively, to select the emulate mode through the command line interface, enter the
command shown below:
EMUG 1 // Enables emulate mode
To disable the emulate mode through the command line interface, enter the command
shown below:
EMUG 0 // Disables emulate mode
-EDID Formats CDF
+HP Bypass
-Emulate
Manufacturer:SNY
Product Code:144
Serial#:7011007
Week:20 Year:1998
-EDID Formats CDF
+HP Bypass
-Emulate
