530 Chapter 16 Testing EDID
Testing HDMI sink device for EDID compliance
Follow this procedure to perform EDID compliance testing on a connected HDMI sink
device.
To perform HDMI sink EDID compliance testing:
1. Set up generator for HDMI sink testing for EDID compliance. See Setting up generator
for HDMI sink device EDID compliance testing on page 525 for details.
2. Press the Content key and choose the EdidHDMI image for testing displays connected
to HDMI output 1 (usee EDIDHDM2 image for HDMI output 2) by pressing the adjacent
soft key.
Alternatively, to select the image through the command line interface, enter the
following command:
IMGL EdidHDMI
IMGU
3. Enable image versions for the EdidHDMI/EdidHDM2 image as follows:
a. Press the Options key. The following menu appears on the generator’s display:
b. Choose the More item by pressing the adjacent soft key until a + and Rendition
appears next to the item.
Alternatively, to enable and view image versions using the command line interface,
enter the following commands:
ISUB 1 // Enables sub images
IVER 1 // Specifies the first image version
IMGU // Activates the image version
4. Press the + key to advance through the image versions and view results for tests 8-1,
8-2, 8-3, 8-17, 8-18, and 8-19. Test descriptions and sample screens are provided
below.
-More
Red+
-NoGamma Green+
-Noise Blue+
+More Rendition: 000
Red+
-NoGamma Green+
-Noise Blue+
