628 Chapter 18 Testing HDCP
To run the 3B series HDCP compliance tests on an HDMI repeater:
For the 882E releases prior to 2.17.x, the 3B-01 test is run multiple times for the two read
configurations: 1) short read and 2) combined read. For the 2.17.x release, these multiple
iterations are handled in the batch mode but you can choose to run them through the
command line as well.
Refer to “ To run the 3B-01 HDCP compliance test on an HDMI repeater: ” on page 635 for
procedures on running this test.
23 3A_04 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Irregular Procedure: (First Part of
Authentication) Verify RO’
24 3A_05 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and DVI
Receiver) Regular Procedure: With DVI Receiver
CPTX:CPTR
I ndex Test Description
