881/882 Video Test Generator User Guide (Rev A.22) 335
Note: Selecting any of the numbered images (for example, Audio_1, Audio_2, etc.) causes
all other channels to be deactivated.
To test an HDMI display using HDMI 8-channel audio from the generator:
1. Set up the generator for HDMI output. See “ Setting up the generator for HDMI testing ”
on page 302.
2. Press the Source key and select the first test format (for example: DMT0660 or
480i2x29).
Alternatively, to select the format using the command line interface, enter the following
commands:
FMTP /tffs0/Library/Formats // Set format path to generator memory
FMTL 480i2x29 // Loads the 480i2x29 format
FMTU // Activates the 480i2x29 format
Image Description
Audio_1 Channel 1 output with adjustable amplitude.
Audio_1f Channel 1 output with adjustable frequency.
Audio_2 Channel 2 output with adjustable amplitude.
Audio_2f Channel 2 output with adjustable frequency.
Audio_3 Channel 3 output with adjustable amplitude.
Audio_3f Channel 3 output with adjustable frequency.
Audio_4 Channel 4 output with adjustable amplitude.
Audio_4f Channel 4 output with adjustable frequency.
Audio_5 Channel 5 output with adjustable amplitude.
Audio_5f Channel 5 output with adjustable frequency.
Audio_6 Channel 6 output with adjustable amplitude.
Audio_6f Channel 6 output with adjustable frequency.
Audio_7 Channel 7 output with adjustable amplitude.
Audio_7f Channel 7 output with adjustable frequency.
Audio_8 Channel 8 output with adjustable amplitude.
Audio_8f Channel 8 output with adjustable frequency.
Audio_X All channels output with adjustable amplitude.
Audio_Xf All channels output with adjustable frequency.
