Chapter 6 Working with Formats
Creating a new format using the Format Editor
The procedure below describes how to create a new format using the Format Editor.
View XML
Opens a window showing the currently displayed
format parameters in XML.
Live Test
Tests the currently displayed format parameters on
the generator.
Set Digital Audio Parameters
Displays a window for setting digital audio
parameters.
Set Digital Video Parameters
Displays a window for setting digital video
parameters.
Clear All
Clears all values and settings from the Format Editor.
Clear Calcs
Clears all calculated values from the Format Editor.
Evaluate
Evaluates values entered and calculates new values
based on the timing algorithms.
Quantize
This feature is not implemented in this release.
(green calculator)
Indicates that the value in the field was calculated by
the Format Editor.
(red calculator)
Indicates that the value in the field was calculated by
the Format Editor, and that the new value has
replaced the value previously in the field.
Feature
Description
