881/882 Video Test Generator User Guide (Rev A.22)
299
The following table lists those generator formats used to test support for HDMI
(EIA/CEA-861-C).
EIA/CEA-861-C Video
Identification Code
Quantum Data format
1
DMT0659, DMT0660
2
480p59, 480p60, 480p59LH, 480p60LH
3
480p59SH, 480p60SH
4
720p59, 720p60
5
1080i29, 1080i30
6
480i2x29, 480i2x30, 480i2xL1, 480i2xL2
7
480i2xS1, 480i2xS2
8
240p2x_1, 240p2x_2, 240p2x_3, 240p2x_4,
240p2xL1, 240p2xL2, 240p2xL3, 240p2xL4
9
240p2xS1, 240p2xS4, 240p2xS3, 240p2xS4
10
480i4x29, 480i4x30, 480i4xL1, 480i4xL2
11
480i4xS1, 480i4xS2
12
240p4x_1, 240p4x_2, 240p4x_3, 240p4x_4,
240p4xL1, 240p4xL2, 240p4xL3, 240p4xL4
13
240p4xS1, 240p4xS2, 240p4xS3, 240p4xS4
14
480p2x59, 480p2x60, 480p2xL1, 480p2xL2
15
480p2xS1, 480p2xS2
16
1080p59, 1080p60
17
576p50, 576p50LH
18
576p50SH
19
720p50
20
1080i25
21
576i2x25, 576i2xLH
22
576i2xSH
23
288p2x_1, 288p2x_2, 288p2x_3, 288p2xL1,
288p2xL2, 288p2xL3
24
288p2xS1, 288p2xS2, 288p2xS3
25
576i4x25, 576i4xLH
26
576i4xSH
27
288p4x_1, 288p4x_2, 288p4x_3, 288p4xL1,
288p4xL2, 288p4xL3
28
288p4xS1, 288p4xS2, 288p4xS3
