Viewing generator configuration information
You can view information about a generator’s configuration, including the firmware and
gateware revisions, installed options, board serial numbers, and so on. The procedure for
accessing this information depends on the type of information you want.
•
For information about the main board and video board memory, use the front panel.
•
For complete generator statistics, view the GenStats image.
•
For firmware and gateware versions, use the command line interface.
This section describes the procedures for accomplishing these methods of accessing
generator configuration information.
To view generator configuration information using the front panel:
1. Press the
Tools key. The Tools menu appears on the generator’s display as shown
below.
2. Choose the
System item by pressing the adjacent soft key. The System menu appears
on the generator’s display.
3. Choose the
About item by pressing the adjacent soft key. A following message appears
on the generator’s display as shown below.
4. Press the
Settings key. The main board information appears. Press the soft key
adjacent to the arrow by Serial Number to see other information about the main board.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
CEC
CalFactor
Host
Network
About
Serial
Gpib
BootFrom
Init
About the Phoenix
Press Settings
About
Main Board ->
Serial Number ->
39298E000000
