4. To save the changes, press the
Enter (Options) key. The following choices appear on
the generator’s display:
To save the changes, choose the
Yes item by pressing the adjacent soft key.
To exit without saving the changes, choose the
No item.
To return to the parameters screen without saving the changes, choose the
Back item.
The following table shows the layout of the format Settings menu.
Parameter Class
Parameter Type
Parameters
Video Signal
Interface
XVSI, AVSI, DVSI
Synchronization
SSST
Gamma Correction
GAMA, GAMC
Active Format
CXAR, EXAR, SXAR, EXCX, SXEX, SXCX, XAFD
Manual Border
XLBW, XRBW, XTBH, XBBH
Canvas
PELD, NPPP
Analog Video
AVST, AVSS, AVSB, AVPS, AVPG, AVCS
Analog Sync
ASSS, ASCT, EQUF
Analog Sync Gates
ASRG, ASGG, ASBG, TSPG
Digital Video
DVST, DVQM, NCPP, NBPC, NLNK, CTLM, BALG,
PREG, DVSP, DVPT, DVSM, DVSS
Digital Sync
DSST, DSCT
Digital Sync Polarity
HSPP, VSPP, CSPP, FSPP, PSPP
Digital Sync Gates
HSPG, VSPG, CSPG, PSPG, LSPG, FSPG,
PCPG
Video Timing
Rates
PRAT, HRAT, VRAT, FRAT, TUNE
Horizontal
HTOT, HRES, HBNK
Vertical
VTOT, VRES, VBNK, SCAN, RFLD
Horizontal Sync
HSPD, HSPW, HSPB, HVPD
Vertical Sync
VSPD, VSPW, VSPB
Composite Sync
HBPD, HBPW, HEPW, EQUB, EQUA, HVSA
Frame Sync
FSPD, FSPW
Probe Sync
PSHD, PSVD, PSPW, PSPM
Audio Signal
Interface
DASI
Apply Settings?
Back
Yes No
