Quantum Data 881 User Manual
Page 262
244
Chapter 9 Analyzing Digital Sources and Cables
6. Choose the
Analyzer item by pressing the adjacent soft key. The Analyzer menu
appears on the generator’s display as shown below.
7. Choose the
Timing item by pressing the adjacent soft key. The Timing menu appears
as shown below.
8. Choose the
Measure item by pressing the adjacent soft key. The Analyzer measures
the video signal and displays the values on the generator’s display. Press the soft key
next to
H to see more values. See the example below for an explanation of the values.
To save timing measurements to a report:
1. Connect the HDMI/DVI transmit device to an HDMI IN connector on the generator.
2. Press the
Interface key repeatedly until the following menu appears:
Timing
CableTest
PIX-ERR
PRN-ERR
*
ReadRGB
TIMING
Measure
Exit
!Report
!
!
TIMING
Stop
V: 525 480 10 2
Exit
!
H: 800 640 16 96
!
→
Horizontal period (pixels)
Active pixels per line
Horizontal pulse delay (pixels)
Horizontal pulse width (pixels)
Vertical period (lines)
Active lines
Vertical pulse delay (lines)
Vertical pulse width (lines)
TIMING
Stop Exit
31500 60.000
!
HS Rate VS Rate
!
→
Horizontal rate
Vertical rate
HDMI IN 1
HDMI IN 2
*
