Configuring the generator’s serial port
The following procedures describe how to change the generator’s default serial port
configuration for a terminal session. You can configure the serial port through either the
front panel, Virtual Front Panel or through the command line interface.
To configure the generator’s serial port through the front panel or Virtual
Front Panel:
1. Press the Tools key. The Tools menu appears on the generator’s display as shown
below.
2. Choose the System item by pressing the adjacent soft key. The System menu appears
on the generator’s display as shown below.
3. Choose the Serial item by pressing the adjacent soft key. The serial port settings
appear on the generator’s display.
Selec
4. Press the Settings key. The following information appears on the generator’s display:
5. To change the baud rate, do the following:
a. Position the blinking cursor on the baud rate setting. To do this, press the soft key
adjacent to the arrow by the baud rate setting to move the cursor left or right until
it appears on the baud rate setting.
b. Press the + or - keys to adjust the baud rate setting up or down.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
CEC
Clock Clone*
CalFactor Server
Network About
Serial GPib
Serial Port
9600 baud
8 N 1
Serial Port
Set Params
BAUD FLOW ->
9600 N ->
