540 Chapter 16 Testing EDID
Example
• SVD – Short Video Descriptor
• 01 – EIA/CEA-861-C Format Video Identification Code (for example, 01, 02, 06,
etc., listed on page 149)
• Y2 – Y indicates color difference. 2 = 4:2:2 pixel sample encoding. 4 = 4:4:4.
• 1 – Represents DMT0659 format, which is the first format (index 1) listed under
video identification code 01 in the table on page 299.
For pixel rate testing, the format naming nomenclature used is shown below:
• SVD – Short Video Descriptor
• 01 – EIA/CEA-861-C Format Video Identification Code (for example, 01, 02, 06,
etc,. listed on page 149)
• H – Indicates the format is using the maximum (H = High) frequency required by
the compliance test; L indicates the format is using the minimum (L = Low)
frequency required by the compliance test.
• 01 – Represents the index of the format as listed under video identification code on
page 149.
To verify proper pixel encoding and pixel rate support:
1. Connect the generator to the display under test.
2. Press the Sink key. The following information appears on the generator’s display.
Short
Video
Descriptor
VIC Format
Index
0 1 Y S V D 2
Component
color
sampling
1
Short
Video
Descriptor
VIC Format
Index
0 1 H S V D 0
Frequency
(High / Low)
1
Manufacturer:SNY
Product Code:144
Serial#:7011007
Week:20 Year:1998
