Quantum Data 881 User Manual
Page 164
146
Chapter 4 Networking Generators
7. Power cycle the generator to set the IP address of the generator.
Setting the file server IP address in the generator
You must enter the IP address of the file server in each generator so the generator can
communicate with the file server. In addition, you can also enter a name (called the Host
Name) for the file server.
To specify the IP address and host name of the file server:
1. Press the
Tools key. The Tools menu appears on the generator’s display as shown
below.
2. Choose the
System item by pressing the adjacent soft key. The System menu appears
on the generator’s display as shown below.
3. Choose the
Server item by pressing the adjacent soft key. The server name and IP
address appear on the generator’s display.
4. Press the
Settings key. The Network Host screen appears on the generator’s display
as shown below.
If the Host Address configuration option is not visible, press the soft key adjacent to the
arrow symbol by Host Name until Host Address appears.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
CEC
*Clock Clone
CalFactor
Server
Network
About
Serial
Gpib
Host IP Address
Host001
206.135.215.218
Network Host
Set Boot Host
Host Address
206.135.215.218
