881/882 Video Test Generator User Guide (Rev A.22) 639
5. Choose the HDMI IN 1 by pressing the adjacent soft key.
6. For the 882E when using the EST, verify that the source is sending in video using the
timing measurement function of the analzyer. Refer to “ To view timing information of an
external HDMI/DVI source signal on a display: ” on page 246 for information on running
the timing test.
Verify that the source is outputting one of the following formats:
• 640x480p at 59.94/60Hz
• 720x480p at 59.94/60Hz
• 720x576p at 50Hz
If the 882 cannot detect the incoming video, enter the following command to turn on the
EST:
QD:PROD:EST // Turns on the EST.
7. Press the Tools key and choose the Reports item by pressing the adjacent soft key.
The following is displayed on the generator’s LCD.
8. Select HDCP to access the HDCP compliance test menu.
The following is displayed on the generator’s LCD.
9. Select EditPCP to define the capabilities of the HDCP device under.
The following is displayed on the generator’s LCD.
The following table describes the test parameters and their settings (gray = N/A).
Parameter Explanation
DUT type The type of device under test. This can be one of Sink,
Source, Repeater, Repeater3AB, or Repeater3C. For
this test, select Repeater3C.
Source Max KSV Specifies the maximum number of KSVs the source can
read. The valid values are 1 through 127.
EDID Packets
Misc HDCP
!CompRpt EditPCP
Source :DUT Type
0
1
+Source_Out_OnlyRep :Source_Authe_Cnt
:Source_Max_KSV
