Quantum Data 881 User Manual
Page 196
178
Chapter 6 Working with Formats
4. To see more options, press the
Options key again. The following appears on the
generator’s display as shown below.
5. To see more options, press the
Options key again. The following appears on the
generator’s display as shown below.
6. Press the
Options key again to see additional options for testing digital displays. The
following appears on the generator’s display as shown below.
To view and modify a format’s settings using the front panel:
1. Press the
Source key and choose a format by pressing the adjacent soft key.
2. Press the
Settings key. The format settings appear on the generator’s display as
shown below. Press the soft keys adjacent to the arrows to see all of the format settings.
Refer to the table below to locate the setting you want to change.
3. To change a setting value:
a. Position the blinking cursor on the value you want to change. To do this, press the
soft key adjacent to the arrow by the setting value to move the cursor left or right
until it appears on the digit you want to change.
b. Adjust the value of the setting up or down by pressing the + or - keys.
MaxRange
MaxRangeTV
NomRange
*ACS
DCS
DSS
-Pedestal
SyncOnR+
SyncOnG+
SyncOnB+
TriLevel+
+ShotProtect AFD: 0
*Production
SafeAction Action-
SafeTitle Title-
Video Signal ->
Interface ->
XVSI AVSI DVSI
<- 1
3 0 ->
