2-62 SC140 DSP Core Reference Manual
Memory Interface
2.4.1.5 Instruction Word Transfers
Instruction words are transferred to the core from memory over the program data bus (PDB) to special
instruction registers in the program dispatch unit (PDU).
The instruction registers can be accessed only with aligned access of 128-bit width (8 instruction words).
Figure 2-24 shows the program memory organization in big and little endian modes. Note that program
data consists of a series of 16-bit instructions. In this example the assembler determines the instructions to
be:
word address $ 00 instruction $ a0b0
word address $ 02 instruction $ c0d0
word address $ 04 instruction $ e0f0
word address $ 06 instruction $ a1b1
word address $ 08 instruction $ c1d1
word address $ 0a instruction $ e1f1
word address $ 0c instruction $ a2b2
word address $ 0e instruction $ c2d2
word address $ 10 instruction $ e2f2
.....
These are to be placed in memory as shown in the following figure.
Figure 2-24. Program Memory Organization in Big and Little Endian Modes
The assembler outputs a byte stream to the loader and therefore corrects for the byte address reversal inside
each 16-bit instruction to achieve the memory results above.
Big Endian Assembler OutputLittle Endian Assembler Output
byte address $00 data $a0byte address $00 data $b0
byte address $01 data $b0byte address $01 data $a0
byte address $02 data $c0byte address $02 data $d0
byte address $03 data $d0byte address $03 data $c0
byte address $04 data $e0byte address $04 data $f0
.....
.....
0
8
16 ($10)
24 ($18)
7 6 5 4 3 2 1 0
Little Endian
a0b0 c0d0 e0f0 a1b1
c1d1 e1f1 a2b2 c2d2
e2f2 a3b3 c3d3 e3f3
0
8
16 ($10)
24 ($18)
0 1 2 3 4 5 6 7
Big Endian
a1b1 e0f0 c0d0
c2d2 a2b2 e1f1
e3f3 c3d3 a3b3 e2f2
a0b0
c1d1
