MOVE.L
SC140 DSP Core Reference Manual A-273
Instruction Fields
C1 CCC Control Registers
C2 CCCC General Registers
C4 DDDDD General Registers
Db jjj Single Source/Destination Data Register
0 0 1 i i i i i i i i i i i i i
1 0 I I I I I I I I I I I I I I
15 8 7 0
MOVE.L #u32,C1 3 1 3 0 0 1 1 0 C C C i i i I I 0 1 1
0 0 1 i i i i i i i i i i i i i
1 0 I I I I I I I I I I I I I I
15 8 7 0
MOVE.L C4,Db 1 1 2 1 1 0 0 D D D D 0 1 0 D w j j j
MOVE.L Db,C4
15 8 7 0
MOVE.L C2,Db 1 1 2 1 1 0 0 C C C C 0 1 1 0 w j j j
MOVE.L Db,C2
000 EMR 010 - 100 — 110 —
001 VBA 011 - 101 SR 111 MCTL
0000 EMR 0100 — 1000 SA0 1100 SA2
0001 VBA 0101 SR 1001 LC0 1101 LC2
0010 - 0110 — 1010 SA1 1110 SA3
0011 - 0111 MCTL 1011 LC1 1111 LC3
00000 D0 01000 D4 10000 R0 11000 R4
00001 B0 01001 B4 10001 N0 11001 M0
00010 D1 01010 D5 10010 R1 11010 R5
00011 B1 01011 B5 10011 N1 11011 M1
00100 D2 01100 D6 10100 R2 11100 R6
00101 B2 01101 B6 10101 N2 11101 M2
00110 D3 01110 D7 10110 R3 11110 R7
00111 B3 01111 B7 10111 N3 11111 M3
Note: If registers D8–D15 or R8–R15 are accessed instead of D0–D7 or R0–R7, a prefix is used.
000 D0 010 D2 100 D4 110 D6
001 D1 011 D3 101 D5 111 D7
Note: If registers D8–D15 are accessed instead of D0–D7, a prefix is used.
