SBR
SC140 DSP Core Reference Manual A-385
0010 1010 1110 0111 0000 0000 1000$2AE7 0080
– 0001 0101 0011 0000 0000 0000 0011$1539 0030
0001 0101 1010 1110 0000 0000 0101$15AE 0050
rounded $15AE 0000
Instruction Formats and Opcodes
Note: ** indicates serial grouping encoding.
Instruction Fields
Da JJJ Single Source Data Register
Dn FFF Single Source/Destination Data Register
Instruction Words Cycles Type Opcode
15 8 7 0
SBR Da,Dn 1 1 1 0 * 1 1 0 0 F F F 1 0 0 1 J J J
000 D0 010 D2 100 D4 110 D6
001 D1 011 D3 101 D5 111 D7
Note: This instruction can specify D8-D15 as operands by using a prefix.
000 D0 010 D2 100 D4 110 D6
001 D1 011 D3 101 D5 111 D7
Note: This instruction can specify D8-D15 as operands by using a prefix.
