Page 355: And #$0ff2e,d2,d1
AND
SC140 DSP Core Reference Manual
A-41
Status and Conditions Changed by Instruction
Example 1
and d2,d1
Example 2
and #$0ff2e,d2,d1
Example 3
and #$ff2e0000,d2,d1
Note:
The value of the immediate $ff2e0000 is extended to $ffff2e0000 before the AND operation with D2.
Register Address
Bit Name
Description
Ln
L
Clears the Ln bit in the destination register.
Register/Memory Address
Before
After
D2
$FF CE66 47F2
L1:D1
$0:$FF D859 6705
$0:$FF C840 4700
Register/Memory Address
Before
After
immediate
$00 0000 FF2E
D2
$00 27A6 98FB
L1:D1
$0:$00 0000 982A
Register/Memory Address
Before
After
immediate
$FF FF2E 0000
D2
$F0 27A6 98FB
L1:D1
$0:$F0 2726 0000
