A-100 SC140 DSP Core Reference Manual
BRA
Example
bra _label2 ; disassembled: bra >*+$8
nop
nop
_label2
Instruction Formats and Opcodes
Instruction Fields
Register/Memory Address Before After
_label (displacement) $0000 000A
PC $0000 0002 $0000 000A
Instruction Words Cycles Type Opcode
15 8 7 0
BRA 1 4 4 1 0 0 0 1 A A A A A A A A A A 1
15 8 7 0
BRA
>label
2 4 4 0 0 1 0 a 0 0 1 A A A 1 1 a a a
1 0 0 A A A A A A A A A A A A a
displacement
( AAAAAAAAAA0 10-bit signed PC relative displacement
displacement
(>label)
aaaaaAAAAAAAAAAAAAAA0 20-bit signed PC relative displacement
