5-18 SC140 DSP Core Reference Manual
Instruction Timing
Table 5-7. Loop Change-Of-Flow Instructions
5.3.2.1 Direct, PC-Relative, and Conditional COF
The SC140 core implements a five-stage pipeline with two stages dedicated to memory access. This results
in the addition of two clock cycles for unconditional COF instructions that use immediate values as well as
the addition of three clock cycles for the PC-relative COF instructions. Conditional change-of-flow
instructions, where the condition is true (meaning the change-of-flow operation is taken), always take an
additional three cycles. When a conditional change-of-flow is determined as not taken (meaning the
condition is false), there are no additional cycles.
JMPD Jump (delayed)
JSR Jump to subroutine
JSRD Jump to subroutine (delayed)
JT Jump if true
JTD Jump if true (delayed)
RTE Return from exception
RTED Return from exception (delayed)
RTS Return from subroutine
RTSD Return from subroutine (delayed)
RTSTK Restore PC from the stack, updating SP
RTSTKD Restore PC from the stack, updating SP (delayed)
TRAP Execute a precise software exception
Instruction Description
BREAK Terminate the loop and branch to an address
CONT Jump to the start of the loop to start the next iteration
CONTD Jump to the start of the loop to start the next iteration (delayed)
SKIPLS Test the active LC and skip the loop if it is equal or smaller than zero
Table 5-6. Non-Loop Change-of-Flow Instructions (Continued)
Instruction Description
