MOVE.W
SC140 DSP Core Reference Manual A-285
MOVE.W
Move Immediate Integer Word (AGU)
MOVE.W
Description
These operations move a signed immediate integer word to a register or a memory address. The address of
the access must be word-aligned.
Operation Assembler Syntax
#s7
→ DR
MOVE.W #s7,DR {–64
≤ s7 < 64}
#s16
→ C4
MOVE.W #s16,C4 {–2 15
≤ s16 < 2
15 }
#s16
→ (aa)
MOVE.W #s16,(a16) {–2 15
≤ s16 < 2
15 }{0
≤ a16 < 2
16 ,W}
#s16
→ (SP–u5)
MOVE.W #s16,(SP–u5) {–2 15
≤ s16 < 2
15 }{0
≤ u5 < 64,W]
#s16
→ (Rn)
MOVE.W #s16,(Rn) {–2 15 ≤ s16 < 2 15 }
#s16
→ (SP+sa16)
MOVE.W #s16,(SP+sa16) {–2 15 ≤ s16 < 2 15 }{–2 15 ≤ sa16 < 2 15 ,W}
MOVE.W #s7,DR
Loads an immediate signed 7-bit value into the LP of a data or address register and sign-extends it.
MOVE.W #s16,C4
Loads an immediate signed 16-bit value into the LP of a general register and sign-extends it.
MOVE.W #s16,(a16)
Writes an immediate signed 16-bit value to an absolute 16-bit address.
MOVE.W #s16,(SP–u5)
Writes an immediate signed 16-bit value to a memory address pointed to by the active stack pointer (SP)
minus an unsigned 5-bit offset that is preshifted left 1 bit.
MOVE.W #s16,(Rn)
Writes an immediate signed 16-bit value to a memory address pointed to by an address register.
MOVE.W
#s16,(SP+sa16)
Writes a 16-bit signed immediate value to a memory address pointed to by the active stack pointer (SP)
plus a signed 16-bit offset.
SIGN EXTENSION
39 0 16
D
0 16 31
SIGN EXTENSION
