MIN
SC140 DSP Core Reference Manual
A-253
MIN
Transfer Minimum Signed Value (DALU)
MIN
Description
Status and Conditions that Affect Instruction
None.
Status and Conditions Changed by Instruction
Example
min d1,d5
Instruction Formats and Opcodes
Note:
** indicates serial grouping encoding.
Instruction Fields
Dg,Dh
GG
Data Register Pairs
Operation
Assembler Syntax
If Dg < Dh, then Dg
→ Dh
MIN Dg,Dh
MIN Dg,Dh
Writes the smaller of two signed values in a data register pair (Dg and Dh) to the second of the two
registers (Dh). If the first register is less than the second, the value of the first register is written to the
second. Otherwise, the second register is unchanged.
Register Address
Bit Name
Description
Ln
L
Clears the Ln bit in the destination register.
Register/Memory Address
Before
After
D1
$00 36AE 3FB4
L5:D5
$0:$00 48FE 4A68
$0:$00 36AE 3FB4
Instruction
Words Cycles Type
Opcode
15
8
7
0
MIN Dg,Dh
1
1
1
*0
*
1
0
1
1
G G
0
1
1
1
1
1
0
1
00
D0,D4
01
D1,D5
10
D2,D6
11
D3,D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
