A-248

SC140 DSP Core Reference Manual

MAX2

Instruction Fields

Dg,Dh

GG

Data Register Pairs

00

D0,D4

01

D1,D5

10

D2,D6

11

D3,D7

Note:

This instruction can specify D8-D15 as operands by using a prefix.
