A-8 SC140 DSP Core Reference Manual
DSP Core Instruction Set
A.1.5.1 One-Word Low Register Prefix
Includes information on grouping, looping, and IFc (conditional execution).
Instruction Formats and Opcodes
Instruction Fields
aaa: Number of instruction words being grouped, including the prefix word minus one. If aaa
equals zero, this is a NOP instruction that is not dispatched for either a single, stand-alone
NOP, or an intra-set NOP [0
≤ aaa ≤ 7].
ccc: Conditional execution of the entire execution set.
In the following table, true/false relates to the state of the T bit in SR. D0, D1, D2, and D3 are
DALU instructions. A0 and A1 are AGU instructions. The numbers relate to the relative word
offset of the instruction from the beginning of the set.
000—Unconditionally executed
001—If true (D0, D2, A0) If false (D1, D3, A1)
010—If true, all the set
011—If false, all the set
100—Reserved
101—Reserved
110—If true (D0, D2, A0), always (D1, D3, A1)
111—If false (D0, D2, A0), always (D1, D3, A1)
p: lpmarkB bit
In the case of a loop with three or more execution sets, the lpmarkB bit is a one in the
execution set that is two before the last execution set in the loop.
Example:
lpmarkB ;(set LA – 2)
;(set LA – 1)
_last ;(set LA)
In the case of a loop with two execution sets such as SA mark, the lpmarkB bit is set in the first
execution set of the loop.
Example:
_start execution_setlpmarkb
_last
execution_set ;(this is a loop on two execution sets)
j: lpmarkA bit
In case of a loop with more than three execution sets, the lpmarkA bit is set in the prefix of the
execution set which is at _last only if there are any SKIPLS, BREAK, CONT, CONTD to
_last, or to _last-1.
Prefix Words Cycles Type Opcode
15 8 7 0
1W LOW REG
PREFIX
1 0 4 1 0 0 1 a a a 0 1 1 0 p j c c c
