MOVE.W
SC140 DSP Core Reference Manual
A-291
Status and Conditions that Affect Instruction
Status and Conditions Changed by Instruction
Example
move.w d1,(r7+4)
Register Address
Bit Name
Description
MCTL[31:0]
AM3–AM0
Address modification bits when updating R0–R7. Otherwise, the
instruction is not affected by MCTL.
SR[18]
EXP
Determines which stack pointer is used when the stack pointer is an
operand. Otherwise, the instruction is not affected by SR.
Register Address
Bit Name
Description
Ln
L
Clears the Ln bit in the destination registers.
Register/Memory Address
Before
After
MCTL
$0000 0000
d1
$FF FFFF FFF1
R7
$0000 000A
$0000 000A
$000E
$FFF1
