4-32 SC140 DSP Core Reference Manual
EOnCE Register Addressing
1C R/W 32 32 EDCA4_REFA EDCA4 reference value A
1D R/W 32 32 EDCA5_REFA EDCA5 reference value A
1E Reserved Address
1F Reserved Address
20 R/W 32 32 EDCA0_REFB EDCA0 reference value B
21 R/W 32 32 EDCA1_REFB EDCA1 reference value B
22 R/W 32 32 EDCA2_REFB EDCA2 reference value B
23 R/W 32 32 EDCA3_REFB EDCA3 reference value B
24 R/W 32 32 EDCA4_REFB EDCA4 reference value B
25 R/W 32 32 EDCA5_REFB EDCA5 reference value B
.......... .......... Reserved addresses ..........
30 R/W 32 32 EDCA0_MASK EDCA0 mask register
31 R/W 32 32 EDCA1_MASK EDCA1 mask register
32 R/W 32 32 EDCA2_MASK EDCA2 mask register
33 R/W 32 32 EDCA3_MASK EDCA3 mask register
34 R/W 32 32 EDCA4_MASK EDCA4 mask register
35 R/W 32 32 EDCA5_MASK EDCA5 mask register
36 Reserved address
37 Reserved address
38 R/W 16 32 EDCD_CTRL EDCD control register
39 R/W 32 32 EDCD_REF EDCD reference value
3A R/W 32 32 EDCD_MASK EDCD mask register
.......... .......... Reserved addresses ..........
40 R/W 16 32 ECNT_CTRL Counter control register
41 R/W 32 32 ECNT_VAL Counter value register
42 R/W 32 32 ECNT_EXT Extension counter value
.......... .......... Reserved addresses ..........
48 R/W 8 16 ESEL_CTRL Selector control register
Table 4-12. EOnCE Register Addressing Offsets (Continued)
EOnCE
Register
Offset
Software
Access
Width
Shift
width
Register Name Description
