DECEQ
SC140 DSP Core Reference Manual
A-141
DECEQ
Decrement and Set T If Equal Zero (DALU)
DECEQ
Description
Status and Conditions that Affect Instruction
None.
Status and Conditions Changed by Instruction
Example
deceq d7
Instruction Formats and Opcodes
Note:
** indicates serial grouping encoding.
Operation
Assembler Syntax
Dn – 1
→ Dn; if Dn==0, then 1→ T, else 0 → T
DECEQ Dn
DECEQ Dn
Decrements a data register (Dn) and sets the T bit if the result is equal to zero.
Register Address
Bit Name
Description
SR[0]
C
Calculates and updates the carry bit in the status register.
SR[1]
T
Set if result = 0, cleared otherwise.
EMR[2]
DOVF
Set if the result cannot be represented in 40 bits.
Ln
L
Clears the Ln bit in the destination register.
Register/Memory Address
Before
After
L7:D7
$0:$00 0000 0001
$0:$00 0000 0000
SR
$00E4 0000
$00E4 0002
EMR
$0000 0000
Instruction
Words Cycles Type
Opcode
15
8
7
0
DECEQ
Dn
1
1
1
0
*
1
0
0
1
F
F
F
1
1
0
1
1
0
1
