MOVE.4W
SC140 DSP Core Reference Manual A-263
move.4w d0:d1:d2:d3,(r0)
Instruction Formats and Opcodes
Instruction Fields
w Read/Write Notation
Da:Db:Dc:Dd k Data Register Quad
EA MMM Effective Address Notation
Rn RRR Address Register
Register/Memory Address Before After
MCTL $0000 0000
R0 $0000 0050
L0:D0 $0:$00 0000 1FEC
L1:D1 $0:$00 0000 2354
L2:D2 $0:$00 0000 38C0
L3:D3 $0:$00 0000 4151
$0050 $1FEC
$0052 $2354
$0054 $38C0
$0056 $4151
Instruction Words Cycles Type Opcode
15 8 7 0
MOVE.4W (EA),Da:Db:Dc:Dd 1 1 1
Note 1: When the form (Rn + N0) is used in EA, the cycle count is increased by 1.
2 1 1 0 0 1 k 0 w 0 0 M M M R R R
MOVE.4W Da:Db:Dc:Dd,(EA)
0 write 1 read
0 D0:D1:D2:D3 1 D4:D5:D6:D7
Note: This instruction can specify D8-D15 as operands by using a prefix. In
such a case, all the registers in the group will be high registers.
000 (Rn+N0) 010 (Rn) 100 (Rn)+N0 110 (Rn)+N2
001 (Rn)– 011 (Rn)+ 101 (Rn)+N1 111 (Rn)+N3
000 R0 010 R2 100 R4 110 R6
001 R1 011 R3 101 R5 111 R7
Note: This instruction can specify R8-R15 as operands by using a high register prefix.
