A-54
SC140 DSP Core Reference Manual
ASLL
Instruction Formats and Opcodes
Note:
** indicates serial grouping encoding.
Instruction Fields
Da
JJJ
Single Source Data Register
Dn
FFF
Single Source/Destination Data Register
Instruction
Words Cycles Type
Opcode
15
8
7
0
ASLL #u5,Dn
1
1
1
0
*
1
1
1
1
F
F
F
1
0
i
i
i
i
i
15
8
7
0
ASLL Da,Dn
1
1
2
1
1
0
1
0
1
F
F
F
0
0
1
0
J
J
J
000
D0
010
D2
100
D4
110
D6
001
D1
011
D3
101
D5
111
D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
000
D0
010
D2
100
D4
110
D6
001
D1
011
D3
101
D5
111
D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
#u5
iiiii
5-bit unsigned immediate data
