IMACLHUU
SC140 DSP Core Reference Manual A-183
IMACLHUU
Integer Multiply-Accumulate
IMACLHUU
Lower Unsigned By Upper Unsigned (DALU)
Description
Status and Conditions that Affect Instruction
None.
Status and Conditions Changed by Instruction
Example
imaclhuu d3,d4,d0
–65,472$FFC0
x 2
$0002
–130,944$FF80
+1
$0001
-130,943$FF81
Operation Assembler Syntax
Dn + (Da.L * Db.H)
→ Dn
IMACLHUU Da,Db,Dn
IMACLHUU Da,Db,Dn
Performs an unsigned integer multiplication of the 16-bit LP of one source data register (Da) with the
16-bit HP of another source data register (Db). It then adds the zero-extended 32-bit product to a
destination data register (Dn). This instruction is optimized for multi-precision-multiplication support.
Register Address Bit Name Description
Ln L Clears the Ln bit in the destination register.
EMR[2] DOVF Set if the result cannot be represented in 40 bits.
Register/Memory Address Before After
D3 $00 0000 0002
D4 $FF FFC0 0000
L0:D0 $0:$00 0000 0001 $0:$00 0001 FF81
EMR $0000 0000
