MOVE.2F
SC140 DSP Core Reference Manual
A-255
Instruction Formats and Opcodes
Notes:
1.
** indicates serial grouping encoding.
2.
When the form (Rn + N0) is used in EA, the cycle count is increased by 1.
Instruction Fields
Da:Db
hh
Data Register Pairs
EA
MMM
Effective Address Notation
Rn
RRR
Address Register
$0050
$6000
$0052
$2000
L2:D2
$0:$00 6000 0000
L3:D3
$0:$00 2000 0000
Instruction
Words Cycles Type
Opcode
15
8
7
0
MOVE.2F (EA),Da:Db
1
1
2
1
0
*
0
1
1
h
h
1
0
1 M M M R R R
00
D0:D1
01
D2:D3
10
D4:D5
11
D6:D7
Note:
This instruction can specify D8-D15 as operands by using a prefix. In such a case, all the registers
in the group will be high registers.
000
(Rn+N0)
010
(Rn)
100
(Rn)+N0
110
(Rn)+N2
001
(Rn)–
011
(Rn)+
101
(Rn)+N1
111
(Rn)+N3
000
R0
010
R2
100
R4
110
R6
001
R1
011
R3
101
R5
111
R7
Note:
This instruction can specify R8-R15 as operands by using a high register prefix.
Register/Memory Address
Before
After
