A-102 SC140 DSP Core Reference Manual
BRAD
Instruction Formats and Opcodes
Instruction Fields
Register/Memory Address Before After
lbl3 (displacement) $0000 000A
PC $0000 0004 $0000 000E
Instruction Words Cycles Type Opcode
15 8 7 0
BRAD 1 4 1 4 1 0 0 0 1 A A A A A A A A A A 0
15 8 7 0
BRAD
>label
2 4
1
Note 1: The branch uses 4 cycles minus the execution time used by execution set in the delay slot. The cycle
count for this instruction cannot be less than 1 cycle.
4 0 0 1 0 a 0 0 0 A A A 1 1 a a a
1 0 0 A A A A A A A A A A A A a
displacement
( AAAAAAAAAA0 10-bit signed PC relative displacement
displacement
(>label)
aaaaaAAAAAAAAAAAAAAA
0
20-bit signed PC relative displacement
