SC140 DSP Core Reference Manual
Event Detection Unit (EDU) Channels and Registers
4.9 Event Detection Unit (EDU) Channels and
Registers
The various event detection channels and corresponding registers are described in the sections that follow.
4.9.1 Address Event Detection Channel (EDCA)
The EDCA can be used to detect the following:
•
Program breakpoint, specified on a specific PC value or range
•
Data address breakpoint, specified on a specific data address or range.
The functionality of these registers is described in the following sections.
4.9.1.1 EDCA Control Registers (EDCAi_CTRL)
EDCAi_CTRL is a 16-bit register used to control the behavior of the corresponding EDCA. The following
sections describe the functionality of each bit in the EDCAi_CTRL register.
Figure 4-21 displays the configuration of the EDCAi_CTRL register.
Figure 4-21. EDCA Control Register (EDCA
i
_CTRL)
Table 4-19 describes the EDCAi_CTRL fields.
BIT 15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
BIT 0
EDCAEN
CS
CBCS
CACS
ATS
BS
TYPE
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
RESET
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Table 4-19. EDCA_CTRL Description
Name
Description
Settings
R
Bits
14-15
Reserved
