A-68 SC140 DSP Core Reference Manual
MOVES.4F
Instruction Formats and Opcodes
Instruction Fields
d1 $0000 $002A
d2 $0000 $0000
d4 $0000 $001A
pc $0006 $0016
Instruction Words Cycles
1
Note 1: If the branch is not taken, it uses 1 cycle. If the branch is taken, it uses 4 cycles minus the time used
by the execution set in the delay slot. The cycle count for this instruction cannot be less than 1 cycle.
Type Opcode
15 8 7 0
BFD 1 1/4 4 1 0 0 0 0 1 0 A A A A A A A A 0
15 8 7 0
BFD
>label
2 1/4 4 0 0 1 0 a 1 1 0 A A A 1 1 a a a
1 0 0 A A A A A A A A A A A A a
displacement
( AAAAAAAA0 8-bit signed PC relative displacement
displacement
(>label)
aaaaaAAAAAAAAAAAAAA
A0
20-bit signed PC relative displacement
Register/Memory Address Before After
