Page 558
A-244
SC140 DSP Core Reference Manual
MACUU
Instruction Formats and Opcodes
Note:
** indicates serial grouping encoding.
Instruction Fields
Dc,Dd
ee
Data Register Pairs
Dn
FFF
Single Source/Destination Data Register
Instruction
Words Cycles Type
Opcode
15
8
7
0
MACUU Dc,Dd,Dn
1
1
1
0
*
1
0
1
1
F
F
F
1
1
0
0
1
e
e
00
D0,D1
01
D2,D3
10
D4,D5
11
D6,D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
000
D0
010
D2
100
D4
110
D6
001
D1
011
D3
101
D5
111
D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
