Page 430
A-116
SC140 DSP Core Reference Manual
CLR
Instruction Fields
Dn
FFF
Destination Data Register
Da
JJJJJ
Source Data Register
Da
jj
Source Data Register
000
D0
010
D2
100
D4
110
D6
001
D1
011
D3
101
D5
111
D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
10000
D0
11100
D2
10100
D4
11110
D6
Note:
This instruction can specify D8-D15 as operands by using a prefix.
00
D1
01
D3
10
D5
11
D7
Note:
If registers D8–D15 are accessed instead of D0–D7, a prefix is used.
