Instruction Timing
SC140 DSP Core Reference Manual 5-15
Table 5-5 summarizes the timing of the various categories of SC140 instructions.
Table 5-5. Instruction Categories Timing Summary
5.3.1 Sequential Instruction Timing
This section describes the timing of non-COF instructions:
• All DALU instructions take one clock cycle to execute.
• All AGU arithmetic instructions take one cycle to execute.
• All memory MOVE instructions (zero-wait-states without contention) take one clock cycle to
execute, unless the addressing mode needs to perform a pre-calculation, in which case, the move
executes in two cycles. For example, the move instructions below take two cycles:
— MOVE.L d0,(Rn + N0)
— MOVE.L d0,(Rn + $5)
— MOVE.L d0,(Rn + Rm)
— MOVE.L d0,(SP + $100)
• All bit mask (BMU) instructions execute in two cycles on registers and memory (zero-wait-states
without contention) with simple addressing modes. However, if a pre-calculation is required, such
as an SP offset, a third cycle is added.
Basic Instruction Category Example/Condition Number of Clock Cycles
DALU MAC D0, D1, D2 1
Data move with simple addressing MOVE.W (R0)+N2, D3 1
Data move with address pre-calculation MOVE.W (R5+N0), D4 2
BMU with simple addressing BMSET.W #$1010, (R0) 2
BMU with address pre-calculation BMSET.W #$1010,(SP+$10) 3
Direct change-of-flow JMP dest 3
PC-relative change-of-flow BRA dest 4
Conditional change-of-flow If condition is true 4
If condition is false 1
Delayed change-of-flow Direct 3 (some cycles used by the
execution set in the delay slot)
PC-relative 4 (some cycles used by the
execution set in the delay slot)
