INC.F
SC140 DSP Core Reference Manual A-199
INC.F
Increment HP of a Data Register by One (DALU)
INC.F
Description
Status and Conditions that Affect Instruction
Status and Conditions Changed by Instruction
Example
inc.f d15
Operation Assembler Syntax
Dn + $00:00010000
→ Dn
INC.F Dn
INC.F Dn
Adds one to the HP of a data register (Dn). Can be used to increment a 16-bit fraction.
Register Address Bit Name Description
SR[2] SM If set, selects 32-bit arithmetic saturation mode.
SR[5:4] S[1:0] Scaling mode bits determine which bits in the result are used in the
Ln bit calculation.
Register Address Bit Name Description
SR[0] C Calculates and updates the carry bit in the status register.
EMR[2] DOVF Set if the result cannot be represented in 40 bits, or if the result
saturates to 32 bits in arithmetic saturation mode.
Ln L If not in arithmetic saturation mode (SR [SM] = 0), calculates and
updates the Ln bit in the destination register. If in arithmetic
saturation mode (SR [SM] = 1), clears the Ln bit in the destination
register.
Register/Memory Address Before After
L0:D15 $0:$FF FFFF FFFF $0:$00 0000 FFFF
SR $00E4 0000 $00E4 0001
EMR $0000 0000
