A-106 SC140 DSP Core Reference Manual
BSR
Instruction Formats and Opcodes
Instruction Fields
Instruction Words Cycles Type Opcode
15 8 7 0
BSR 1 4 4 1 0 0 0 0 0 1 A A A A A A A A 1
15 8 7 0
BSR
>label
2 4 4 0 0 1 0 a 0 1 1 A A A 1 1 a a a
1 0 0 A A A A A A A A A A A A a
displacement
( AAAAAAAA0 8-bit signed PC relative displacement
displacement
(>label)
aaaaaAAAAAAAAAAAAAA
A0
20-bit signed PC relative displacement
