Pipeline
SC140 DSP Core Reference Manual 5-3
Table 5-1 shows a typical pipeline flow. For the machine to advance to the next instruction cycle, all of the
five operations at the current cycle must be completed.
Table 5-2 provides an overview of the operations performed at each stage of the pipeline.
Table 5-1. Pipeline Example
Operation
Instruction Cycle
1 2 3 4 5 6 7 8 9 10 11 12
Pre-fetch i1 i2 i3 i4 i5 i6
Fetch i1 i2 i3 i4 i5 i6
Decode i1 i2 i3 i4 i5 i6
Address
Generation
i1 i2 i3 i4 i5 i6
Execution i1 i2 i3 i4 i5 i6
Table 5-2. Pipeline Stages Overview
Pipeline Stage Description
Pre-fetch • Generate addresses for program fetch
• Update fetch counter (FC)
Fetch • Read fetch set from memory
Dispatch • Dispatch instructions
• Decode AGU instructions
Address Generation • Decode DALU instructions
• Generate addresses for data load and store operations
• Perform address calculations: normal and change-of-flow
• Perform AGU arithmetic instructions
• Update AGU registers
Execution • Read source operands to DALU
• Read source register for memory store operations
• Perform data calculations (multiply and add)
• Write DALU results to destination registers
• Write destination register for memory load operations
