Page 418
A-104
SC140 DSP Core Reference Manual
BREAK
Instruction Formats and Opcodes
Instruction Fields
Instruction
Words Cycles Type
Opcode
15
8
7
0
BREAK label
2
4
4
0
0
1
0
0
0
0
0
A
A
A
0
0
0
1
1
1
0
0
A
A
A
A
A
A
A
A
A
A
A
A
a
displacement
aAAAAAAAAAAAAAAA0
16-bit signed PC relative displacement.
The encoding is the displacement with bit
0 stripped and replaced by the sign bit.
