MACR
SC140 DSP Core Reference Manual
A-237
0.000 0000 1000$0080
x 0.000 0000 1000$0080
0.000 0000 0000 0000 1000$000080000
+0.000 0000 0000 0111 0000$0007
rnd0.000 0000 0000 0111 1000$00078
0.000 0000 0000 1000 0000
$0008
Instruction Formats and Opcodes
Note:
** indicates serial grouping encoding.
Instruction Fields
k
Accumulation Notation
Da,Db
JJJJJ
Data Register Pairs
EMR
$0000 0000
Instruction
Words Cycles Type
Opcode
15
8
7
0
MACR
±Da,Db,Dn
1
1
1
0
*
1
0
0
1
F
F
F
k
0
J
J
J
J
J
15
8
7
0
MACR
±Da,Da,Dn
1
1
1
0
*
1
0
1
0
F
F
F
1
1
1
1
k
j
j
0
add
1
subtract
00000
D0,D4
01000
D2,D4
10000
D0,D0
11000
D1,D2
00001
D0,D5
01001
D2,D5
10001
D0,D1
11001
D1,D3
00010
D0,D6
01010
D2,D6
10010
D0,D2
11010
D5,D6
00011
D0,D7
01011
D2,D7
10011
D0,D3
11011
D5,D7
00100
D1,D4
01100
D3,D4
10100
D4,D4
11100
D2,D2
00101
D1,D5
01101
D3,D5
10101
D4,D5
11101
D2,D3
00110
D1,D6
01110
D3,D6
10110
D4,D6
11110
D6,D6
00111
D1,D7
01111
D3,D7
10111
D4,D7
11111
D6,D7
Notes:
1.
This instruction can specify D8-D15 as operands by using a prefix.
2.
Register pair order can be inverted for clarity because the order of operation is not important
for multiply operations.
3.
The JJJJJ encoding does not include the pairs: D1–D1, D3–D3, D5–D5, and D7–D7. These
are covered in the jj encoding.
Register/Memory Address
Before
After
