4-64 SC140 DSP Core Reference Manual
Event Selector (ES) Registers
4.10.3 Event Selector Mask Debug Exception
Register (ESEL_DI)
This 16-bit register has one bit for each source of event selection. Setting the appropriate bit enables the
related source to cause a debug exception.
Figure 4-25 displays the bit configuration of ESEL_DI.
Figure 4-25. Event Selector Mask Debug Exception (ESEL_DI)
If multiple sources are configured to cause a debug exception, they are ANDed or ORed according to the
value of the SELDI bit in the ESEL_CTRL. For more information, see
Section 4.10.1, “Event Selector
Control Register (ESEL_CTRL).” If all the bits are set to zero, the ES does not issue a debug exception.
4.10.4 Event Selector Mask Enable Trace Register
(ESEL_ETB)
This 16-bit register has one bit for every source of the ES. Setting the appropriate bit configures the related
source to enable trace.
Figure 4-26 displays the bit configuration of ESEL_ETB.
Figure 4-26. Event Selector Mask Enable Trace (ESEL_ETB)
If multiple sources are configured to enable trace, they are ANDed or ORed according to the value of the
SELETB bit in the ESEL_CTRL. If all the bits are set to zero, the ES does not enable trace.
The same event cannot be configured to both enable and disable tracing.
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 BIT 0
DEBUGE
V
EE4 EE3 EE2 EE1 EE0 COUNT EDCD
EDCA
7
EDCA
6
EDCA
5
EDCA
4
EDCA
3
EDCA
2
EDCA
1
EDCA
0
TYPE rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
RESET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 BIT 0
DEBUGE
V
EE4 EE3 EE2 EE1 EE0
COUN
T
EDCD
EDCA
7
EDCA
6
EDCA
5
EDCA
4
EDCA
3
EDCA
2
EDCA
1
EDCA
0
TYPE rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
RESET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
