BMTSET
SC140 DSP Core Reference Manual A-85
Example 2
bmtset #$4238,d4.l
Instruction Formats and Opcodes
Instruction Fields
DR HHHH Data/Address Register
Register/Memory Address Before After
SR $00E4 0000 $00E4 0002
immediate $4238
d4 $00 1234 5678 $00 1234 5678
Instruction Words Cycles Type Opcode
15 8 7 0
BMTSET #u16,DR.H 2 2 3 0 0 0 0 1 1 1 0 i i i 1 H H H H
1 0 1 i i i i i i i i i i i i i
15 8 7 0
BMTSET #u16,DR.L 2 2 3 0 0 0 0 1 1 1 0 i i i 0 H H H H
1 0 1 i i i i i i i i i i i i i
0000 D0 0100 D4 1000 R0 1100 R4
0001 D1 0101 D5 1001 R1 1101 R5
0010 D2 0110 D6 1010 R2 1110 R6
0011 D3 0111 D7 1011 R3 1111 R7
Note: This instruction can specify D8-D15 or R8-R15 as operands by using a high register prefix.
#u16 iiiiiiiiiiiiiiii 16-bit unsigned immediate data
