A-134
SC140 DSP Core Reference Manual
CONT
Instruction Formats and Opcodes
Instruction Fields
Instruction
Words
Cycles
1
Note 1: If LC > 1, CONT uses 3 cycles. If LC
≤ 1, CONT uses 4 cycles.
Type
Opcode
15
8
7
0
CONT label
2
3/4
4
0
0
1
0
0
0
1
1
A
A
A
0
0
0
1
1
1
0
0
A
A
A
A
A
A
A
A
A
A
A
A
a
displacement
aAAAAAAAAAAAAAAA0
16-bit signed PC relative displacement. The
encoding is the displacement with bit 0
stripped and replaced by the sign bit.
