MOVE.L
SC140 DSP Core Reference Manual A-279
MOVE.L
Move Long (AGU)
MOVE.L
Description
These operations move a signed long word (32-bit data) from memory to a register, or from a register to
memory. Absolute addresses, offsets, and address register values must be long word-aligned (the address
must be a multiple of 4). The programmer should ensure that the effective address resides on a long word
boundary.
Operation Assembler Syntax
(aa)
↔ DR
MOVE.L (a32),DR {0
≤ a32 < 2
32 ,L}
MOVE.L DR,(a32)
(aa)
↔ C4
MOVE.L (a16),C4 {0
≤ a16 < 2 16 ,L}
MOVE.L C4,(a16)
(Rn + u3)
↔ DR
MOVE.L (Rn+u3),DR {0
≤ u3 < 32,L}
MOVE.L DR,(Rn+u3)
(Rn + s15)
↔ DR
MOVE.L (Rn+s15),DR {–2 14
≤ s15 < 2
14 ,L}
MOVE.L DR,(Rn+s15)
(Rn + Rr)
↔ DR
MOVE.L (Rn+Rr),DR
MOVE.L DR,(Rn+Rr)
(EA)
↔ DR
MOVE.L (EA),DR
MOVE.L DR,(EA)
(Rn)
↔ C3
MOVE.L (Rn),C3
MOVE.L C3,(Rn)
(SP – u6)
↔ DR
MOVE.L (SP–u6),DR {0
≤ u6 < 256,L}
MOVE.L DR,(SP–u6)
(SP + s15)
↔ C4
MOVE.L (SP+s15),C4 {–2 14 ≤ s15 < 2 14 ,L}
MOVE.L C4,(SP+s15)
SIGN
EXTENSION
39 0 32
0 31
D
