7-4 SC140 DSP Core Reference Manual
Programming Rule Notation
7.4.2 Sequencing Rules
Sequencing rules enforce the VLES sequencing semantics by specifying the minimum distance between
different VLES having instructions “A” and “B”. They use the notation “at least n VLES are required
between” or “the minimum number of VLES between” instructions “A” and “B”. For a minimum VLES
distance between “A” and “B”, the VLES having “A” and “B” are not included in this count.
7.4.2.1 Cycle Counts
Rules A.1 and A.2 specify a minimum cycle distance between “A” and “B” events. They use the notation
“at least n cycles are required between when A and when B” occur. This takes into account the exact
pipeline stages when “A” and “B” occur. By grouping a multiple cycle instruction with “A”, the minimum
cycle distance may be met without scheduling additional VLES between “A” and “B”. For a minimum
cycle distance between “A” and “B”, the cycles when “A” and “B” occur are not included in this count.
7.4.2.2 Conditional Execution
If instructions “A” or “B” are conditional or conditioned by an IFc instruction, they will execute only if
their execution condition is true. If “A” and “B” have mutually exclusive execution conditions, their
execution cannot violate a sequencing rule. The simulator knows if “A” and “B” execute from its
simulation trace, and detects programming rules considering their conditional execution. However, the
assembler cannot know the T bit state when “A” or “B” execute. So the assembler detects sequencing rules
independent of conditional execution. That is, it assumes all conditional instructions always execute.
7.4.2.3 Simulator Execution Counts
A conditional VLES that is not executed (becomes a NOP) is counted by the simulator as one VLES for
VLES-based sequencing rules. For cycle-based sequencing rules, a conditional VLES that is not executed
(becomes a NOP) is counted by the simulator as one cycle.
7.4.3 Register Read/Write
In this chapter the programming rules use the notation “read” and “write” to refer to whole register sources
and destinations, respectively. This notation applies to instruction source and destination operands, both
explicit and implicit (implied), as specified in each instruction definition in
Appendix A.2, “Instructions,”
on page A-19.
7.4.3.1 Register Names
Some rules apply to selected registers — address, data, or program control. The rules specify the registers
using the names given in
Table A-3: Register Abbreviations on page A-3.
